The application of industrial endoscopes in electronics manufacturing is primarily reflected in the following aspects. Combining their technical principles and advantages, they provide key support for quality control and efficiency improvement in electronics manufacturing:
Internal Inspection of Circuit Boards
Circuit Connection and Solder Quality: Industrial endoscopes can penetrate deep into circuit boards to inspect the integrity of circuit connections and the presence of defects such as cold solder joints, short circuits, or cracks at solder joints, ensuring the electrical performance and reliability of the circuit boards.
Internal Component Defect Inspection: For micro-components (such as chips, capacitors, and resistors), endoscopes can observe the internal structure for cracks, bubbles, foreign matter, or packaging defects, preventing device failures caused by internal component issues.
Precision Assembly Process Monitoring
Assembly Quality Verification: During the assembly of electronic products, endoscopes can monitor the assembly of key components in real time, such as connectors being properly seated and seals being intact, ensuring that assembly precision meets requirements.
Microstructure Inspection: For micro-structures within consumer electronics products such as mobile phones and tablets (such as camera modules and sensor components), endoscopes can assist in detecting assembly gaps, residual foreign matter, or structural deformation. Electronic Equipment Maintenance and Troubleshooting
Inspecting Internal Cleanliness of Equipment: During maintenance of electronic manufacturing equipment (such as SMT placement machines and reflow ovens), endoscopes can inspect the interior of the equipment for tin slag, dust, or foreign material buildup, preventing equipment failure or product quality issues caused by contamination.
Fault Location and Repair: When electronic equipment malfunctions, endoscopes can quickly locate the fault point (such as a short circuit within a circuit board or a burned component), allowing for preliminary diagnosis without disassembling the equipment, shortening repair time.
Technical Principle
Optical Imaging System: Images are transmitted through an objective lens, a relay lens, or optical fibers, combined with high-brightness LED or laser illumination to ensure clear images even in low-light environments.
Electronic Video Endoscope: Utilizes a CCD or CMOS image sensor to convert optical signals into electrical signals. Digital processing technology enhances image resolution and contrast, enabling real-time display and recording.
Flexible Insertion Tube Design: The insertion tube can be bent or rotated to accommodate complex structural inspections, such as inspections within confined spaces within circuit boards or irregularly shaped components.
Core Advantages
Non-destructive Testing: Inspections can be completed without disassembling equipment or damaging components, eliminating secondary damage and efficiency losses caused by disassembly.
Efficient and Convenient: Inspections can be completed by a single operator, supporting real-time image transmission and recording, significantly improving inspection efficiency.
Digital Management: Inspection data can be stored as images or videos for subsequent analysis, traceability, and report generation, meeting the digital requirements of smart manufacturing.
Adaptable to Complex Environments: Dustproof, waterproof, and high-temperature resistant, it operates stably in the high-temperature, high-humidity, and corrosive environments found in electronics manufacturing.
Typical Case Studies
Circuit Board Defect Detection
An electronics manufacturer used an industrial endoscope to inspect high-density interconnect (HDI) circuit boards, successfully identifying tiny cracks in internal wiring and preventing batch scrapping of products due to circuit board failures.
The endoscope's 3D measurement function accurately assessed the height and shape of solder joints to ensure they met process requirements.
Internal Inspection of Microcomponents
During the semiconductor packaging process, endoscopes are used to inspect the connection quality between chip pins and the package substrate to ensure there are no cold solder joints or short circuits.
Internal structural inspection of microcapacitors identified packaging air bubbles and enabled timely adjustments to the production process.
Equipment Maintenance and Troubleshooting
A mobile phone manufacturer used an endoscope to inspect the inside of an SMT placement machine's feeder and discovered a blockage caused by solder paste residue. Cleaning and maintenance prevented equipment downtime.
During server motherboard troubleshooting, the endoscope quickly located the location of a burned-out capacitor inside the circuit board, shortening repair time.
Future Development Trends
Intelligent Upgrade: Incorporating AI image recognition technology, it automatically identifies defect types (such as cracks and foreign matter) and generates inspection reports, improving inspection efficiency and accuracy. Ultra-miniaturized design: Developing insertion tubes with thinner diameters (e.g., under 1mm) to meet the needs of inspecting smaller electronic components.
Multi-functional integration: Integrating functions such as temperature measurement and spectral analysis enables simultaneous multi-parameter inspection, enhancing comprehensive inspection capabilities.
Wireless and portable: Wireless transmission technology enables remote inspection, while a portable design meets the flexible inspection needs of electronics manufacturing sites.
Industrial endoscopes, with their non-destructive, efficient, and digital features, have become a key tool for quality control and equipment maintenance in the electronics manufacturing industry. With continuous technological advancements, their application scenarios will further expand, providing strong support for the intelligent and sophisticated development of electronics manufacturing.
