Rigid Endoscope
Applicable Applications: Inspection of straight lines or small angles, such as the internal structure of automotive engine blocks and cylinders, and inspection of the inner cavities of pump bodies and pipe fittings during machining.
Advantages:
Durability: Simple structure, suitable for frequent inspections.
High Precision: Supports extremely fine diameter designs (e.g., as small as 1.7mm). Equipped with a high-definition imaging module, it accurately captures minute defects (e.g., cracks and pores).
Flexible Endoscope
Applicable Applications: Inspection of complex paths, such as aerospace engine turbine blades, the interior of gas turbine ducts, wind turbine gearboxes, and other confined spaces.
Advantages:
Flexibility: Bends over 180° and supports 360° panoramic imaging.
Intelligent Functions: Integrated AI algorithms automatically identify defects such as cracks and pores, improving inspection efficiency.
Ultra-Fine Diameter Design
Technical Parameters: Minimum diameter can reach less than 1mm, equipped with a high-resolution imaging device (e.g., a 520,000-pixel CMOS). Advantages:
Non-destructive testing: Eliminates equipment disassembly, reducing maintenance costs.
High-definition imaging: Uniform illumination technology ensures clear imaging even in confined spaces.
Automotive Manufacturing
Engine Inspection: Internal wear and cylinder block cracks in turbochargers.
Transmission Inspection: Foreign objects in cross-holes and blockages in hydraulic valve blocks.
New Energy Vehicles: Verify battery pack weld quality and inspect for foreign objects inside motors.
Aerospace
Aerospace Engines: Detect cracks in turbine blades and combustion chambers to prevent failures caused by high temperature and high pressure.
Rocket Engines: Inspect rocket body welds and sand inclusions to ensure structural integrity.
Fuel Systems: Real-time monitoring of pipeline corrosion and blockages.
Energy Equipment
Gas Turbines: Detect micron-level defects on blade surfaces to extend equipment life.
Petrochemical Industry: Offshore platform pipeline inspection, rapidly scanning long-distance pipelines to identify hidden corrosion spots.
Nuclear Power Equipment: Non-destructive inspection of reactor internal structures.
Heavy Machinery
Machine Tool Inspection: Check for wear on gearboxes and guide rails.
Excavators: Detect foreign objects in hydraulic systems to prevent damage to hydraulic components. Crane: Detection of broken wires inside the wire rope to prevent breakage risks. III. Advantages and Case Studies
Core Advantages
Nondestructive Testing: Avoids secondary damage caused by equipment disassembly and reduces maintenance costs.
Efficiency: Combining real-time imaging with data analysis quickly locates defect size.
Intelligence: AI algorithms automatically identify defects, improving inspection accuracy.
Classic Case Studies
Case 1: An automobile manufacturer inspected an engine block and discovered a 0.5mm crack, avoiding a recall.
Case 2: During aircraft engine maintenance, a micron-level crack in a turbine blade was detected, enabling preemptive component replacement to prevent failure.
Case 3: During a petrochemical pipeline inspection, a 200-meter pipeline scan was completed in 4 hours, identifying three corrosion points and preventing potential leaks.
Requirements Analysis
Identify the inspection target (e.g., engine, pipeline), environment (high temperature, corrosive media), and accuracy requirements (micron-level defects).
Equipment Selection
Select a rigid or flexible endoscope based on your needs, focusing on the following parameters:
Diameter: Ultra-fine design (e.g., φ1.7mm or smaller).
Viewing angle: Wide-angle or directional.
Light source: LED or rear-mounted illumination, IP67 waterproof rating.
Operation Training
Technicians must master probe control, image analysis, and measurement functions (e.g., ruler, negative display).
Process Development
Standardized inspection steps:
Pre-treatment: Clean the inspection port.
Probe Insertion: Insert slowly to avoid collisions.
Image Acquisition: Capture images from multiple angles and mark defect locations.
Report Generation: Automatically generate inspection reports containing defect size and location.
Maintenance and Calibration
Regularly check probe wear and light source brightness to ensure equipment is in optimal condition.
Intelligent Upgrades: Integration with 5G communications enables remote, real-time inspection and data analysis.
Material Innovation: High-temperature and corrosion-resistant probes adapt to extreme environments.
AI Deep Integration: Automatic defect classification and predictive maintenance improve inspection efficiency and accuracy.
By deeply integrating its technical characteristics with the needs of the machinery industry, industrial endoscopes have become a key tool in nondestructive testing, significantly improving inspection efficiency and equipment safety, and driving the manufacturing industry towards intelligent and refined processes.
